SPECIFICATIONS
Brand Name: REDMAGIC
Charging Power: 80W
Design: Flip
Display Size: 6.85
Touch Screen: Yes
CONTENT OF THE ORIGINAL BOX
Redmagic 11S Pro X 1
Transparent Cover X 1
Original charger of 80 W (American standard) x 1
Data Cable USB-C X 1
Tool for ejection of SIM tray X 1
Card de guarantee X 1
Documentation
Specifications
Basic Parameters
Height: 163,82mm
Width: 76,54mm
Depth: 8.9mm
Weight: 230g
Material: Central frame + back panel in Corning glass
Combinations of Memory:
Subzero: 12 GB + 256 GB / 16 GB + 512 GB
Nightfreeze: 16 GB + 512 GB
Ultra LPDDR5X + UFS 4.1
Protection against dust and water:
IPX8 * rated with unique dust-proof design
Screen
Size: 6.85 inch BOE X10 FHD +
Refresh Rate: Up to 144Hz
Touch Sampling Rate: Up to 3000Hz, 360Hz Multi-Touch
Resolution: 2688x1216 pixels
Ratio of Screen: 20:9 Ratio
Type: AMOLED
Maximum brightness: 1,800 nits
Material: Corning Gorilla Glass
Range of colors: 100% DCI-P3
Accuracy of colors: E1
System of cooling
The revolutionary cooling system REDMAGIC AquaCore
Foil of copper under the canvas
High-conductivity graphene under the screen
3D steam chamber of 13.116 mm²
Compound of liquid metal 3.0
Intermediate structure in aerospace-grade aluminum alloy
Gel with high thermal conductivity
Upgraded 24,000-RPM waterproof turbo fan
Base of copper foil
Aerospace-grade aluminum high-speed air duct
Circulating Liquid Cooling
Hardware
Processor: Snapdragon 8 Elite Gen 5 (leading version)
CPU Cores: The Oryon 2 + 6 Architecture
CPU Core Frequency: Up to 4.74 GHz
GPU: Adreno
R4 Redcore
Connectivity
Network
YES: Dual nano-SIM
5G Network: SA and NSA
Modes: SA (Standalone) and NSA (Non-Standalone)
5G (NR) bands: N1/2 / 3 / 5 / 7 / 8 / 20 / 26 / 28 / 38/N40/N41/66/N77/N78
4G LTE:
TDD: B34 / 38 / 39 / 40 / 41 / 42
FDD: B1 / 2 / 3 / 4 / 5 / 7 / 8 / 12 / 17 / 18 / 19 / 20 / 26 / 28 / 66
3G
UMTS B1/3/5/5 / 6 / 8 / 19
2G
GSM 3/3 / 5/7
Wi-Fi: 802.11 a/b/g/n/ac/AX
Tri-band (2.4 GHz / 5 GHz / 6 GHz)
HBS (Simultaneous High Band)
Bluetooth: 5.4
GPS: Dual GPS (L1 + L5)
NFC: Yes
HDMI: Requires adapter
DP: Support 4K HD Video
Cameras
Rear Camera
Resolution: 50 MP + 50 MP + 2 MP
Sensor:
OV50E40, 1/1. 55 ", 7P F1.88
OV50D40, 1/2. 88 ", 6P F2.0
Optical Stabilization of Image (OIS)
7P Lens
Anti-reflective coating (APL)
Front Camera
Resolution: 16 MP, with improvement by AI algorithm
Sensor: OV16A, 1/2. 77 ", 5P, F2.0
Sensors and Biometric Authentication
Ultrasonic 3D Fingerprint Reader, Accelerometer, Electronic Compass, Gyroscope, Proximity Sensor, Ambient Light Sensor, Infrared Sensor
Biometric Authentication
Recognition of Fingerprint, Facial Recognition
Operating System
REDMAGIC OS 11.5 based on Android 16.0
Battery & Fast Charger
Capacity: 7,500 mAh (single cell)
Fast Charging with Wire: 80W
Wireless Fast Charging: Up to 80W
Supports reverse charging with wire and wireless.
Doors
USB 3.2 Gen 2, Type-C, DisplayPort, Dual Nano-SIM slot, 3.5mm headphone jack
Audio Formats-Supported
Playback: WAV, AAC, MP3, AMR, FLAC, OGG, APE
Recording: MP3
Stereo Speakers: 1015 + 1115E
Supported formats of video
Playback: 3GP, ASF, AVI, FLV, M2TS, MKV, MOV, MP4, MPG, MTSTS, WEBM, WMV, MPEG, M4V
Recording: MP4
Image formats are supported
Playback: JPEG, PNG, GIF, BMP, WBMP, HEIC
Output: JPEG
Special Features
Side Trigger Buttons: Touchpads with touch sampling rate of 520Hz
Tactile reflex: 0815 linear motor on X axis
Magic key: By default, it opens GameSpace, but users can customize it for quick access to other functions, such as taking photos or recording videos with the rear camera, activating the flashlight, start the voice recorder, or switch to silent or vibrate mode.
RGB Lighting: Fully-customizable lighting effects. Adds a new RGB light strip to the side frame while retaining the fan, side triggers, and logo lights.
Resources
Highlights
World's fastest mobile processor
Qualcomm Snapdragon 8 Elite Gen 5 processor, leading version, REDMAGIC RedCore R4 and Energy Cube 3.0.
Ice in Motion
REDMAGIC AquaCore liquid cooling system enhanced with Liquid Metal 3.0, a 13,116 mm² steam chamber, and a 24,000 RPM turbo fan.
Impressive Performance
Upgraded 7500 mAh battery with 80 W wired and wireless fast-charging.
Visualized Perfection.
Expanded AMOLED display with 2688x1216 resolution, advanced touch controls, 144Hz refresh rate, and screen-to-body ratio of 95.3%.
Elegant Design
Fully flat back with dynamic RGB illumination and visible liquid cooling.
Adapted to Reality
IPX8 water and dust resistance, 360-degree antenna and dual-band Wi-Fi, support for two SIM + NFC + USB 3.2 Gen 2 chips with screen expansion and secure 3D ultrasonic access.
Capture what matters
50 MP main camera with optical image stabilization (OIS) + 50 MP ultra-wide-angle lens, 16 MP front-facing camera, and image algorithms optimized for superior photo quality.
Dive into action!
Large dual speakers, optimized 0815 haptic motor, and 4D haptic feedback with 520Hz shoulder triggers for fast, accurate control.
Designed for the Elite Players
Elegant, sophisticated design with visible cooling
Visible transparent coating
The unique transparent back allows you to see the cooling system in action.
Soft touch
No protrusion of the camera for a cleaner and more comfortable grip.
Increase performance
Aesthetic RGB back strip
Dazzling Screen
High-resolution display of 2688x1216
Slow? It's not part of our vocabulary.
Designed for speed, the system delivers fast application startup, fluid multitasking, and flawless performance even during intense gaming and processing.
Take your gaming experience to the next level.
Increase your speed, processing power, and game resources.
RedCore R4 REDMAGIC
A dedicated gaming chip designed to optimize performance and cooling with customizable in-game effects, smooth visuals in Super 2K resolution with Qualcomm technology, and intelligent power and heat management.
Energy Cube 3.0 and Snapdragon Elite Gaming
Real-time optimization and dynamic allocation of CP
